SPECIFICATIONS
OVERVIEW
- Accuracy
- ±2°C (±3.6°F) or ±2% of reading, for ambient temperature 10°C to 35°C (50°F to 95°F) and object temperature above 0°C (32°F)
- Detector Type
- Uncooled microbolometer
- Field of view (FOV)
- 45° × 34°
- IR Resolution
- 320 × 240 pixels
- Multi Spectral Dynamic Imaging (MSX)
- IR image enhanced with visible camera detail
- Object Temperature Range
- –20°C to 250°C (–4°F to 482°F)
- Packaging Size
- 385 × 165 × 315 mm (15.2 × 6.5 × 12.4 in)
- Thermal Sensitivity/NETD
- <0.06°C (0.11°F) / <60 mK
CONNECTIONS & COMMUNICATIONS
- Interface
- USB Micro: Data transfer to and from PC and Mac device
- WiFi
- •Standard: 802.11 b/g/n •Frequency range: •2400–2480 MHz •5150–5260 MHz •Max. output power: 15 dBm
ENVIRONMENTAL
- Emissivity table/correction
- Emissivity table of predefined materials/variable from 0.1 to 1.0
- Encapsulation/Drop
- IP 54 (IEC 60529)/2m (6.6 ft.)
IMAGING & OPTICAL
- Color palettes
- Black & white, iron, and rainbow
- Focus
- Focus free
- Image Adjustment
- Automatic/Manual
- Image Frequency
- 9 Hz
- Image Modes
- Thermal MSX®, thermal, picture-in-picture, thermal blending, digital camera
- Minimum Focus Distance
- 0.5 m (1.6 ft.)
- Picture-in-Picture
- IR area on visual image
- Digital Camera Resolution/FOV
- 640 × 480/55° × 43°
MEASUREMENT & ANALYSIS
- Spot Meter
- Center spot; box with min./max.
METER DATA
- Camera weight incl battery
- 0.575 kg (1.27 lb.)
- Display
- 3.0 in. 320 × 240 color LCD
POWER
- Battery type & operating time
- Rechargeable 3.6 V Li ion battery; approx. 4 hours typical use
STORAGE MEDIA
- File Formats
- Standard JPEG, 14-bit measurement data included
