SPECIFICATIONS
OVERVIEW
- Accuracy
- ±2°C (±3.6°F) or ±2% of reading for ambient temperature 15°C to 35°C (59°F to 95°F) and object temperature above 0°C (32°F)
- Alarm
- Moisture, insulation, and measurement
- Color alarm (isotherm)
- Above, below, interval, condensation, insulation
- Detector Type
- Uncooled microbolometer, 17µm
- Field of view (FOV)
- 24° × 18°
- IR Resolution
- 240 × 180 (43,200 pixels)
- Laser Pointer
- Yes; dedicated button
- Object Temperature Range
- -20°C to 120°C (-4°F to 248°F) 0°C to 650°C (32°F to 1200°F)
- Compass GPS
- Yes; automatic GPS image tagging
- Area Box
- 1 in live mode
CONNECTIONS & COMMUNICATIONS
- Communication Interfaces
- USB 2.0, Bluetooth, Wi-Fi, DisplayPort
- Storage Media
- Removable SD card
- Video Out
- DisplayPort over USB Type-C
- METERLiNK
- Yes; several readings
ENVIRONMENTAL
- Operating Temperature Range
- -15°C to 50°C (5°F to 122°F)
- Storage Temperature Range
- -40°C to 70°C (-40°F to 158°F)
IMAGING & OPTICAL
- Color palettes
- Iron, Gray, Rainbow, Arctic, Lava, Rainbow HC
- Digital Camera
- 5 MP, 53° × 41° FOV
- Digital Zoom
- 1-4x continuous
- f-number
- f/1.3
- Focus
- Manual
- Image Fequency
- 30 Hz
- Image Modes
- Infrared, visual, MSX®, Picture-in-Picture
- Non-radiometric IR video streaming
- H.264 or MPEG-4 over Wi-Fi; MJPEG over UVC or Wi-Fi
- Picture-in-Picture
- Centered infrared area on the visual image
- Radiometric IR video recording
- Real-time radiometric recording (.csq)
- Radiometric IR video streaming
- Over UVC
- Spectral Range
- 7.5 – 14.0 µm
- Weight [incl lens]
- 1 kg (2.2 lbs)
- MSX
- Embosses visual details on full resolution thermal image
- Non-Radiometric IR & Visual Video Recording
- H.264 to memory card
MEASUREMENT & ANALYSIS
- Measurement Presets
- No measurement, center spot, hot spot, cold spot, 3 spots, hot spot-spot
- Spot Meter
- 3 in live mode
- Thermal Sensitivity
- <0.04°C at 30°C (86°F), 24° lens
METER DATA
- Display
- 4°, 640 × 480 pixel touch screen LCD with auto-rotation
OTHER
- Shock and Vibration and Drop and Encapsulation
- 25 g / IEC 60068-2-27, 2 g / IEC 60068-2-6, IP 54 /IEC 60529; EN/UL/CSA/PSE 60950-1
PHYSICAL FEATURES
- Dimensions (L x W x H)
- 278.4 × 116.1 × 113.1 mm (11.0 × 4.6 × 4.4 in)
POWER
- Battery operating time
- Approx. 2.5 hours at 25°C (77°F) ambient temperature and typical use
- Battery Type
- Li-ion battery, charged in camera or on separate charger
SHIPPING INFORMATION
- Packaging
- Infrared camera with lens, battery (2 ea), battery charger, front protection, straps (hand, wrist), hard transport case, lanyards, lens caps, lens cleaning cloth, power supplies, 8 GB SD card, Torx wrench, cables (USB 2.0 A to USB Type-C, USB Type-C to USB Type-C, USB Type-C to HDMI)
STORAGE MEDIA
- Image File Format
- Standard JPEG with measurement data included
