Deskripsi Clamp Meter atau Tang Ampere Hioki CM3281
Tang ampere atau clamp meter Hioki CM3281 adalah tang ampere 2000A AC yang memiliki rentang suhu pengoperasian yang luas dari -25 ° C hingga 65 ° C, dengan inti penjepit tipis dan ringkas, serta sensor arus fleksibel opsional yang dapat Anda pasang agar Anda dapat memasuki tempat yang paling sempit.
Model No. (Order Code)
| CM3281 | Average rectified |
|---|
Spesifikasi Tang Ampere Hioki CM3281
| AC Current range | 42.00 to 2000 A, 3 ranges (50 Hz to 60 Hz, Average rectified), Basic accuracy 50-60 Hz: ±1.5% rdg. ±5 dgt. |
|---|---|
| DC Voltage range | 420.0 mV to 600 V, 5 ranges, Basic accuracy: ±1.0 % rdg. ±3 dgt. (at 4.2 V range) |
| AC Voltage range | 4.200 V to 600 V, 4 ranges (45 to 500 Hz, Average rectified), Basic accuracy 45-66 Hz: ±1.8% rdg. ±7 dgt. (at 4.2 V range) |
| Resistance range | 420.0 Ω to 42.00 MΩ, 6 ranges, Basic accuracy: ±2.0 % rdg. ±4 dgt. (at 420 Ω range) |
| Other functions | Continuity check: Buzzer sounds at 50 Ω ±40 Ω or less, Data hold, Auto power save, Drop-proof from height of 1 meter |
| Power supply | Coin type lithium battery (CR2032) ×1, Continuous use 120 hours |
| Core jaw diameter | φ 46 mm (1.81 in), Jaw dimension: 65 mm (2.56 in) W × 13 mm (0.51 in) D |
| Dimensions and mass | 57 mm (2.24 in) W × 198 mm (7.80 in) H × 16 mm (0.63 in) D, 103 g (3.6 oz) |
| Accessories | Carrying case ×1, TEST LEAD L9208 ×1, Coin type lithium battery CR2032 (for trial purposes only) ×1, Instruction manual ×1, Download guide ×1, Operating precautions ×1 |
Spesifikasi Clamp Sensor Tambahan Hioki CT6280 (Opsional)
| Core jaw dia. | φ 130 mm (5.12 in) (Cable cross-section diameter: 5 mm (0.20 in); tip cap diameter: 7 mm (0.28 in)) |
|---|---|
| AC Current | 419.9 A/ 4199 A, 2 ranges (±3.0 % rdg. ±5 dgt.) |
| Cable length | 800 mm (31.5 in) |
