| AC A (50/60Hz) | 20/200mA/200A ±3%rdg±5dgt (20/200mA/100A) ±5%rdg±5dgt (200A) |
|---|---|
| AC A (WIDE) | 20/200mA/200A ±2%rdg±4dgt [50/60Hz] (20/200mA/0 – 100A) ±5%rdg±6dgt [40 – 400Hz] (20/200mA/0 – 100A) ±5%rdg±4dgt [50/60Hz] (100.1 – 200A) |
| Conductor size | Ø24mm max. |
| Frequency response | 40 – 400Hz |
| Effect of external stray magnetic field Ø15mm 100A | 10mA AC max. |
| Safety Standard | IEC 61010-1 CAT III 300V IEC 61010-2-032 |
| Power source | LR-44 (1.5V)× 2 |
| Dimensions | 149(L)× 60(W) × 26(D)mm |
| Weight | 120g approx. |
| Included Accessories | 9090 (Carrying Case) LR-44 × 2 Instruction Manual |
